JY-142 Coin Changer Control Board with wires, Banknote exchange to Coin or Token Main control board for washing machine device

TIMER0059
Quantity:
-
+
(999 available)
Please select the information you wantX
  • Description
  • Reviews

WELCOME to My Shop Commodity, Competitive Price, Customer First !
Your business with me will be a pleasant experience for you. I am dedicated to bring joy, safe and top-quality products for you. All the products I offer in my store come with fashion style, superior quality but cheaper price all the time. When you place order, please do not hesitate to leave more detailed requirements you want, and then I will arrange the goods for you as soon as possible. First time, we do business; next time, we become friends. Hope you enjoy the whole process!



Support Dropshipping and Wholesaling.

100% Original and Good Quality with Free After-sale Warranty.





specification:
ompatible Brand/Model: None
Compatible: Game Console
Voltage input: DC 12V
Output / maximum load: switch control, without voltage / 5A
Applicable motor type: 6 holes / 7 holes
Working method: receive the signal- Greater than motor withdraw coins- Greater than the number of sensor signals reaches the set value- Greater than stop withdrawing coins
Maximum number of coins withdrawn: up to this set value, output 5V voltage and warning sound
Memory: adjustable
1: Display
2: White lead
3: Pause for mode 01:02
4: Flow sensor No.11 input signal reach MAX LIMIT
5: Output: Control first solenoid valve
6: Output: Control second solenoid valve
7: Input devices-coin acceptor, bill acceptor, or card reader:
YELLOW: DC12V, WHITE: input signal, BLACK: GND
8: AC jack-5.5mm * 2.1mm
9: Flow sensor No.10 input signal reach MAX LIMIT
10: Input: from flow sensor No.6
11: Input: from flow sensor No.5
12: button START for MODE 01:02
13-16: Button S4, S3, S2, and S1
Color: green
Material: PCB
Package Contents:
1 * time control board
1 * wire
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
